Overview & Basic Info
Model NO.
YXD65S-DK34L-DWL
Type
Network Version AD Player
Protection
IP65 Waterproof/Dustproof
Product Description
Project Custom Design Outdoor LCD Wall Mount Digital Billboard
Weatherproof Excellence:
IP65 rated protection grade, ensuring full waterproof, dustproof, and lightning proof performance for any outdoor environment.
Visual Performance:
3000nits high brightness with photosensitive system that adjusts automatically to surrounding light. 3D digital filter noise reduction.
Smart Thermal Management:
Built-in fan cooling/heating system with intelligent temperature sensing to maintain stable operation.
Robust Security:
IK10 certified glass and anti-theft design with internal locks to prevent unauthorized movement.
| Model Specs |
43" / 49" |
55" |
65" |
75" |
86" |
| Product Size (mm) |
794*1315*130 |
861*1950*130 |
1010*2200*1510 |
1150*2400*155 |
1380*2355*250 |
| Weight |
197KG |
220KG |
250KG |
300KG |
350KG |
| Contrast Ratio |
3000:1 |
3000:1 |
4000:1 |
4000:1 |
4000:1 |
| Resolution |
1920 * 1080 / 3840 * 2160 |
Advanced System Features
Management: Adopt distributed management, support remote or local control via Wired, WIFI, or 4G networks.
Split Screen: Supports intelligent split-screen display, composable with audio, video, web pages, and real-time captions.
Hardware: Galvanized sheet architecture with anti-corrosion coating for 7+ years of outdoor durability.
| System Parameters (Android Default) |
| CPU | Quad-core Cortex-A17 up to 1.8GHz |
| RAM/ROM | 2GB DDR3 / 16GB NAND Flash |
| Connectivity | Wi-Fi 802.11 b/g/n, RJ45 Ethernet |
| OS Version | Android 6.0 / 7.1 / 9.0 |
| Media Formats | Video (MPG, AVI, MP4), Image (JPG, GIF, PNG, BMP) |
Application & Packaging
Frequently Asked Questions
What is the protection level for outdoor use?
The machine features an IP65 protection grade, making it fully waterproof, dustproof, and lightning-proof. The shell is made of 1.5mm galvanized sheet with outdoor powder coating, resistant to corrosion for over 7 years.
How does the screen perform in direct sunlight?
It uses a 2500-3000 nits high-brightness industrial panel. It includes an intelligent photosensitive system that automatically adjusts brightness based on the surrounding environment for optimal visibility.
What cooling system is integrated?
It features an intelligent through-air fan cooling system with temperature-sensing probes. It can automatically adjust fan speed or shut off the display in extreme high temperatures to protect the hardware.
What operating systems are supported?
The default system is Android (supporting versions 6.0/7.1/9.0). We also offer an optional Windows system with Intel Core i3/i5/i7 processors.
Is the device secure against theft or vandalism?
Yes, the device is IK10 certified for impact resistance. The base and hangers are designed with internal locks to prevent the machine from being moved by removing external screws.
What kind of content management is available?
It supports remote management via Wi-Fi or 4G. You can easily manage split screens, set multi-stage timing switches, and preview program lists through the management software.
